The Story
Frame: FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle
Fork:RockShox 35 Gold RL 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset
Front Travel:150
Rear Shock:RockShox Deluxe Select RT | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ
Rear Travel:140
Headset:FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Stem:Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Handelbar:Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Grips:ODI Elite Pro Lock On
Brakes:Shimano MT4120 4 Piston | Resin Pads
Shifters:Shimano Deore 12spd
Rear Derailleur:Shimano Deore 12spd
Cranks & Chainring:Shimano Deore | 32T | 24mm Spindle | Crankarm Length: XS - SM = 165mm | MD - XL = 170mm
Bottom Bracket:Shimano SM-BBMT500
Cassette:Shimano Deore 10-51T 12spd
Chain:Shimano M6100
Front Hub:Shimano TC500 | 15x110m | 28H
Rear Hub:Shimano TC500 Boost 148mm | 28H
Spokes:2.0 Stainless
Rims:WTB ST i30 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl
Tires:F: Maxxis Dissector 2.4 WT EXO Tubeless Ready // R: Maxxis Dissector 2.4 WT EXO Tubeless Ready
Seatpost:X Fusion Manic Composite 30.9mm | XS = 125mm | SM = 150mm | MD = 170mm | LG - XL = 200mm
Saddle:WTB Volt 142
